康纳-温菲尔德最新的最准确和安静的OXCO-OX200-SC,OX200-SC-019.44M

2023-06-25 10:06:54

康纳 温菲尔德新闻4.1

康纳-温菲尔德最新的最准确和安静的OXCO-OX200-SC,OX200-SC-019.44M,奥罗拉,伊利诺伊州-我们最新的OXCO恒温晶振,OX200-SC是我们最安静,准确和稳定10.0MHzOCXO。OX200-SC设计用于以下应用作为使用IEEE1588PTP主时钟的IP回程,需要非常高的频率稳定性,非常严格的初始校准和非常低的老化。这些规范可以消除或大大延长初始或定期重新校准的时间。

OX-200-SC是10.0MHz,12Vdc,烤箱第三泛音SC切割晶体CO-8封装中带有电子频率控制(EFC)的振荡器。其频率稳定性为±1.5ppb温度范围为0°~70°c。频率校准保证小于±25ppbEFC设置为2.5V。EFC可以在0-4V范围内改变±0.2ppm的频率。规定30天后的老化量小于0.2ppb/天,5年后的总老化量小于60ppb/天。频率收集器保证5年的频率低于0.1ppm。超过5%电压或负载变化的稳定性较小小于±0.3ppb。输出为10mhzLVCMOS输出。典型相位噪声电平为-85dBc/Hz@1Hz,-115dBc/Hz@10hz,-135dBc/Hz@100hz,-145dBc/Hz@1khz,-150dBc/Hz@10khz。该OX200-SC被安置在一个标准的5针密封的“欧洲”CO8封装与13.46毫米高,长36毫米,宽27毫米。OH200符合RoHS标准,无铅。

康纳温菲尔德1.1

康纳-温菲尔德最新的最准确和安静的OXCO-OX200-SC,OX200-SC-019.44M

功能和配置

•OCVCXO

•12V直流操作

•频率稳定性:±1.5ppb

•温度范围:0至70°C

•LVCMOS输出

•低抖动和相位噪声

•符合RoHS标准/无铅 晶振厂家

原厂代码 品牌 型号 类型 频率 输出 电压 频率稳定度 工作温度
OX9143S3-020.0M Connor-Winfield OX914xS3 OCXO 20MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
OX9143S3-020.0M Connor-Winfield OX914xS3 OCXO 20MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
OX9143S3-020.0M Connor-Winfield OX914xS3 OCXO 20MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
DOC020F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOC020F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOC020F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOC050F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC052F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC102F-040.0M Connor-Winfield DOC OCXO 40MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-040.0M Connor-Winfield DOC OCXO 40MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-040.0M Connor-Winfield DOC OCXO 40MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC050F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC020F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOC020F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOC020F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±20ppb 0°C ~ 70°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOC052F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-020.0M Connor-Winfield DOC OCXO 20MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
OH4610LF-040.0M Connor-Winfield OH4 OCXO 40MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-025.0M Connor-Winfield OH4 OCXO 25MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
ASOF3S3-020.0M Connor-Winfield ASOF3S3 OCXO 20MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
ASOF3S3-012.8M Connor-Winfield ASOF3S3 OCXO 12.8MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
DOC102F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC052F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-012.8M Connor-Winfield DOC OCXO 12.8MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
ASOF3S3-010.0M Connor-Winfield ASOF3S3 OCXO 10MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
OX400-620LF-020.0M Connor-Winfield OX400-620LF OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OX400-620LF-024.576M Connor-Winfield OX400-620LF OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-38.88M Connor-Winfield OH4 OCXO 38.88MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OHSM100-60803CF-010.0M Connor-Winfield OHSM100-60803CF OCXO 10MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
OX9140S3-012.8M Connor-Winfield OX914xS3 OCXO 12.8MHz LVCMOS 3.3V ±140ppb 0°C ~ 70°C
OX9140S3-012.8M Connor-Winfield OX914xS3 OCXO 12.8MHz LVCMOS 3.3V ±140ppb 0°C ~ 70°C
OX9140S3-012.8M Connor-Winfield OX914xS3 OCXO 12.8MHz LVCMOS 3.3V ±140ppb 0°C ~ 70°C
DOC100F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
DOC100F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
DOC100F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
DOC100F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
DOC100F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
DOC100F-010.0M Connor-Winfield DOC OCXO 10MHz LVCMOS 3.3V ±100ppb 0°C ~ 70°C
OX9143S3-010.0M Connor-Winfield OX914xS3 OCXO 10MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
OX9143S3-010.0M Connor-Winfield OX914xS3 OCXO 10MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
OX9143S3-010.0M Connor-Winfield OX914xS3 OCXO 10MHz LVCMOS 3.3V ±140ppb -40°C ~ 85°C
DOC050F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC050F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb 0°C ~ 70°C
DOC102F-024.576M Connor-Winfield DOC OCXO 24.576MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-024.576M Connor-Winfield DOC OCXO 24.576MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-024.576M Connor-Winfield DOC OCXO 24.576MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC052F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC052F-019.44M Connor-Winfield DOC OCXO 19.44MHz LVCMOS 3.3V ±50ppb -40°C ~ 85°C
DOC102F-049.152M Connor-Winfield DOC OCXO 49.152MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-049.152M Connor-Winfield DOC OCXO 49.152MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOC102F-049.152M Connor-Winfield DOC OCXO 49.152MHz LVCMOS 3.3V ±100ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OHSM100-60803CF-020.0M Connor-Winfield OHSM100-60803CF OCXO 20MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-024.576M Connor-Winfield OH4 OCXO 24.576MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
