微孔雾化片,不锈钢雾化片,加湿器雾化片

当前位置：首页 » 雾化片 » 微孔雾化片

: 雾化片,微孔雾化片,16mm雾化片,103KHZ雾化片频率：103KHZ尺寸：16mm 频率参数可按要求定做

雾化片,微孔雾化片,16mm雾化片,103KHZ雾化片

谐振阻抗(Ro) :max. 80Ω 静态电容(Cp):3000pF±15%

■特点：雾化片颗粒径均匀；雾化粒径易于调整，无长存液体负载，雾化效率极高，无空化现象，雾化稳定，结构简化小型，金属箔喷嘴无虑压电陶瓷潮湿黏度低于15 C P 值之液体均可雾化。
■应用：此规格超声波雾化片主要应用在加湿微量雾化、玩具喷雾、医疗喷雾治疗、香薰理疗雾化设备中。

相关产品说明下载PDF文件

: 雾化片,微孔雾化片,16mm雾化片,108KHZ雾化片频率：108KHZ尺寸：16mm 频率参数可按要求定做

雾化片,微孔雾化片,16mm雾化片,108KHZ雾化片

谐振阻抗(Ro) :max. 80Ω 静态电容(Cp):3000pF±15%

■特点：雾化片颗粒径均匀；雾化粒径易于调整，无长存液体负载，雾化效率极高，无空化现象，雾化稳定，结构简化小型，金属箔喷嘴无虑压电陶瓷潮湿黏度低于15 C P 值之液体均可雾化。
■应用：此规格超声波雾化片主要应用在加湿微量雾化、玩具喷雾、医疗喷雾治疗、香薰理疗雾化设备中。

相关产品说明下载PDF文件

: 雾化片,微孔雾化片,16mm雾化片,112KHZ雾化片频率：112KHZ尺寸：16mm 频率参数可按要求定做

雾化片,微孔雾化片,16mm雾化片,112KHZ雾化片

谐振阻抗(Ro) :max. 80Ω 静态电容(Cp):3000pF±15%

■特点：雾化粒径均匀；雾化粒径易于调整，无长存液体负载，雾化效率极高，无空化现象，雾化稳定，结构简化小型，金属箔喷嘴无虑压电陶瓷潮湿黏度低于15 C P 值之液体均可雾化。
■应用：此规格超声波雾化片主要应用在加湿微量雾化、玩具喷雾、医疗喷雾治疗、香薰理疗雾化设备中。

相关产品说明下载PDF文件
