MtronPTI晶振今天推出了M2520系列小尺寸差分晶振，M200124TLN-100M0000室外6G基站晶振

MtronPTI晶振今天推出了M2520系列小尺寸差分晶振，M200124TLN-100M0000室外6G基站晶振。M2520系列振荡器支持小于100fs RMS的抖动，具有非常严格的频率公差，低至+/-20ppm。该振荡器具有2.5 x 2.0mm的小尺寸，支持-40至+85C的宽工作温度范围，并具有高达212.5 MHz的标准和定制输出频率，使其成为空间有限和环境条件具有挑战性的应用的理想选择。M2520系列适用于各种应用，包括光模块、网络、服务器、存储、电信和其他需要低抖动和小尺寸的应用。

特点:

频率范围:13.5 MHz ~ 212.5 MHz

LVPECL和LVDS输出选项

+/-20ppm稳定性，其他选项可选

<100fs RMS抖动@ 156.25 MHz

3.3V或2.5V

2.5 x 2.0毫米表面安装包6垫布局

工作温度范围:-45℃~ 85℃

MtronPTI晶振今天推出了M2520系列小尺寸差分晶振，M200124TLN-100M0000室外6G基站晶振，MtronPTI Crystal today introduced the M2520 series small form factor differential output crystal oscillator. M2520 series oscillators support less than 100fs RMS Jitter with extremely tight frequency tolerance down to +/-20ppm. This oscillator has a small form factor of 2.5 x 2.0mm, supports a wide operating temperature range of -40 to +85C, and has standard and custom output frequencies up to 212.5 MHz, making it ideal for applications where space is limited and environmental conditions challenging. The M2520 series is suitable for a variety of applications, including optical modules, networking, servers, storage, telecom, and other applications which require low jitter and a small form factor.

Features:

Frequency range: 13.5 MHz to 212.5 MHz

LVPECL and LVDS output options

+/-20ppm stability, other options available

<100fs RMS jitter @ 156.25 MHz

3.3V or 2.5V

2.5 x 2.0 mm surface mount package with 6 pad layout

Operating temperature range: -45°C to 85°C
